Why is the span length ratio of end span/approach span to its neighboring inner spans usually about 0.75?

Saad Iqbal | 🗓️Modified: May 27, 2016 | ⏳Read Time: 2 min | 👁Post Views: 374
From aesthetic point of view, an odd number of spans with a decrease in length in the direction of abutment is desirable. Moreover, spans of equal length are found to be boring. However, the arrangement of irregular span lengths is not recommended because it gives a feeling of uneasiness.
From structural point of view, for a multi-span bridge with equal span length, the sagging moment at the mid-span of the end span/approach span is largest. In order to reduce this moment, the span length of end span/approach span is designed to be 0.75 of inner spans. However, this ratio should not be less than 0.40 because of the effect of uplifting at the end span/approach span support.
Note: End span refers to the last span in a continuous bridge while approach span refers top the first span of a
bridge.
bridge.Vincent T. H. CHU
